600 PSI Full Port Brass Ball Valve with Female Threaded Ends

SUNRICH FLOW supplies 600 PSI full port brass ball valves with Female x Female threaded ends for water supply, plumbing, HVAC, compressed air, oil and compatible non-corrosive fluid applications.

This model features a 2-piece brass valve body, full port flow passage, red lever handle and internal threaded connections on both ends. With a listed pressure rating of 600 PSI WOG non-shock, it is suitable for buyers requiring a heavier-duty brass ball valve for plumbing and pipeline shut-off systems.

The valve is available from 1/4″ to 2″. BSP, BSPT and NPT thread standards, handle colors, valve body marking and customized packaging can be supplied according to different market requirements.

Key Features

• 2-piece brass valve body
• Full port design for reduced flow restriction
• Female x Female threaded ends
• Red lever handle for quarter-turn operation
• 600 PSI / 41.3 bar WOG non-shock rating
• Temperature range from -20°C to 120°C
• Size range from 1/4″ to 2″
• BSP, BSPT and NPT thread options
• OEM logo and handle marking available
• Customized packaging for importers and distributors

Technical Specifications

Product Name: 600 PSI Full Port Brass Ball Valve with Female Threaded Ends
Valve Type: Ball valve
Body Structure: 2-piece
Port Type: Full port
Body Material: Brass
Surface Finish: Natural brass
Connection Type: Female x Female threaded ends
Thread Standard: BSP, BSPT or NPT available
Handle Type: Red lever handle
Available Sizes: 1/4″, 3/8″, 1/2″, 3/4″, 1″, 1-1/4″, 1-1/2″, 2″
Pressure Rating: 600 PSI / 41.3 bar WOG non-shock
Temperature Range: -4°F to 248°F / -20°C to 120°C
Working Media: Water, oil, compressed air and compatible non-corrosive fluids
OEM Service: Logo, handle color, labels and customized packaging available
Packing: Neutral box, color box, export carton or customized packaging

Full Port Design

The full port structure provides an internal flow passage close to the nominal pipeline diameter when the valve is fully open. It helps reduce pressure loss and flow restriction compared with reduced-port ball valves.

600 PSI Pressure Rating

This model is listed with a 600 PSI WOG non-shock pressure rating, equivalent to approximately 41.3 bar. Final suitability should be confirmed according to the working medium, operating temperature, sealing material and applicable market standard.

A WOG pressure marking does not automatically mean the valve has a specific gas-service certification. EN331, CSA, UL or other certification requirements should be confirmed separately.

Applications

• Residential and commercial plumbing
• Water supply systems
• HVAC pipeline systems
• Compressed air systems
• Oil and compatible fluid pipelines
• Pump and equipment connections
• General pipeline shut-off control
• Wholesale and plumbing distribution

Thread Options

BSP, BSPT and NPT thread options can be supplied. Buyers should confirm the required thread standard before quotation.

BSP threads are commonly requested for Brazil, Europe and many international plumbing markets. NPT threads are commonly used in Mexico, Colombia, the United States and other American markets.

OEM and Packaging

SUNRICH FLOW supports:

• Valve body logo marking
• Customized handle printing
• Red, blue or customized handle colors
• Private labels and barcode labels
• Customized inner boxes
• Export cartons and pallet packaging

Quality Control

Common inspection items include brass body appearance, thread accuracy, handle operation, ball rotation, valve leakage, pressure testing and packaging inspection.

FAQ

Q1: What does 600 PSI WOG mean?
It indicates a listed non-shock pressure rating of 600 PSI for compatible water, oil and gas-type service conditions. Final medium suitability and certification must be confirmed separately.

Q2: What does full port mean?
Full port means the internal flow passage is designed to reduce flow restriction when the valve is fully open.

Q3: What sizes are available?
The available size range is 1/4″ to 2″.

Q4: Can you supply BSP and NPT threads?
Yes. BSP, BSPT and NPT options can be supplied according to customer requirements.

Q5: Can the valve be used for certified gas systems?
Gas certifications such as EN331, CSA or UL depend on the exact model and must be confirmed before ordering.

Q6: What information is needed for quotation?
Please provide the size, thread standard, quantity, working pressure, working medium, packaging requirement and destination port.
